ROASTING COATING PAN
Capacities : 1 GONI TO 5 GONI
Additional applications :
- KURKURE, KURMURA, CHEESE BALL, POHA ROASTING MASALA COATING
Descriptions :
- S.S 304 (8% Nickel) HOT AIR, THIRMIC HEATED & LPG CYLINDER
- All fitting like MOTOR & GEAR BOX WITH ELECTRIC PANNAL.
Our range of tablet coating pans is extensively used for sugar and film coating of tablets, pallets and granules. The unit comprises of ellipsoidal shaped pan fabricated using stainless steel sheet and mounted on the gearbox shaft, which is driven by an electric motor. These tablet coating pan are available in standard and GMP model with SS 304 or 316 contact parts.
Features:
- The complete drive unit is enclosed in a sturdy cabinet.
- Hot air blower with flexible SS Pipe heaters are provided with thermostat control for fast drying
- Heaters are interlocked with the blower motor therefore unless the blower is on, heater does not start.
| WIN-12 | WIN-24 | WIN-36 | WIN-42 | WIN-48 | WIN-60 | WIN-72 | |
|---|---|---|---|---|---|---|---|
| Loading Capacity in Kg | 8 | 45 | 80 | 100 | 150 | 210 | 275 |
| Motor H.P. | 0.5 | 1 | 1 | 3 | 3 | 5 | 5 |
| Rpm of Pan | 10/30/90 | 10/30/90 | 10 to30 | 10 to 25 | 10 to 25 | 10 to 12 | 8 & 10 |
| Blower Motor H.P. | 0.25 | 0.33 | 0.33 | 0.33 | 0.33 | 1 | 1 |
| Blower Capacity (Max. CFM) | 50/100 | 50/100 | 100/150 | 100/150 | 150/200 | 250/400 | 350/400 |
| Heater Capacity in K.W. | 0.5 | 1 | 1.5 | 3 | 3 |
CHOCOLATE COATING PAN RANGE
Conventional rotary pans are extremely versatile and can be used for coating and polishing a wide range of products such as nuts, dried fruit, licorice centers, jelly beans etc, using chocolate masses or sugar solution coatings.
These machines can be supplied in either copper or stainless steel construction, and in ‘onion’ or ‘tulip’ shapes.
We supply machines either with a fixed angle base, or with variable angle from 0-80%. The variable angle pan has a motorized tilt unit and scale to indicate the angle.
The pans can be supplied with a fixed speed, 3 speed, or variable drive mechanisms depending on the Client’s preference. The pans can be rotated in clockwise or anti-clockwise directions.
Technical Specifications:
| Pan rotation speed | 25/30/35rpm (3 speed) 15-40rpm (vari-speed pulley) 20-50rpm (Inverter) |
|---|---|
| Pan drive motor | 0.8kw |
| Tilt drive motor | 0.4kw |
| Hot air blowers | 4.5kw heaters. Temperature range from ambient up to 70° C. Air blower variable from 1 to 4.5m³/min. Filter supplied. |
| Cold air blowers | As above with heaters off. |
Optional extras:
- 2 piece cover for pan aperture
- Sound insulation
- Digital display for rotation speed
- Dust extraction unit
- Syrup preparation and spray units
- Chocolate preparation and spray units
